TP-LINK CPE610 5GHz 300Mbps 23dBi Outdoor CPE MIMO antenna Access Point Client Bridge Repeater AP Router AP Client Router Passive PoE Weatherproof

TP-Link CPE610 5GHz 300Mbps 23dBi Outdoor CPE MIMO antenna Access Point Client Bridge Repeater AP Router AP Client Router Passive PoE Weatherproof Up to 300Mbps on 5GHz wireless data rates 23dBi high-gain directional 2×2 MIMO antenna and a dedicated metal reflector, ideal for long-distance application Excellent beam directivity, improved latency and noise cancellation Innovative snap-lock parts make for fast assembly and a sturdy structural design keeps CPE610 stable even in strong winds Durable IP65 weatherproof enclosure along with 15 kV ESD and 6 kV lightning protection ensures all-weather suitability TP-Link Pharos MAXtream TDMA technology improves throughput, capacity and latency performance Pharos Control gives administrators a free, centralized management system AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes Passive PoE supports to allow flexible deployment and convenient installation HARDWARE FEATURES Processor Qualcomm 560MHz CPU, MIPS 74Kc Memory 64MB DDR2 RAM,8MB Flash Interface 1 1 10/100Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button Power Supply Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) Voltage range: 16-27VDC Dimensions 360 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) (No mount) Antenna Gain 23dBi Antenna Beamwidth 9°(Azimuth), 7°(Elevation) Protection 15KV ESD Protection 6KV Lightning Protection Enclosure Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dust proof design WIRELESS FEATURES Wireless Standards IEEE 802.11a/n Proprietary Protocol TDMA Mode (with Pharos MAXtream enabled) Wireless Speeds Up to 300Mbps (40MHz,Dynamic) Up to 144.4Mbps (20MHz,Dynamic) Up to 72.2Mbps (10MHz,Dynamic) Up to 36.1Mbps (5MHz,Dynamic) Frequency 5.15~5.85GHz Transmit Power Max. 29dBm/790mW (Adjustable power by 1dBm) SOFTWARE FEATURES Operating Modes AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP Client)
